Parent Layer: Rail

Name: RailroadCrossings

Display Field: CrossingId

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>The dataset provided includes point data for use in GIS that represents public rail crossings in North Carolina. Only crossings with open or inactive crossing statuses are included; closed crossings have been omitted from this dataset. Attributes for each crossing include the crossing's Federal Railroad Administration (FRA) identification number and the latitude and longitude of the crossing. Crossing location and status were verified by cross-referencing FRA public crossing database with North Carolina Department of Transportation Rail Division's crossing database, railroad company track charts and aerial imagery. Where in doubt, crossing status has been confirmed by contacting the rail company, land owner, or municipality within whose jurisdiction the crossing falls. The attributes are derived directly from NCDOT's State Authoritative Rail and Highway (SARAH) database.</SPAN></P></DIV></DIV></DIV>

Service Item Id: 0a716c8bb35546749fdc3e69621029ab

Copyright Text: North Carolina Department of Transportation Rail Division, Moffatt & Nichol Engineers, WGI

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 493586.7904793024
YMin: 72807.77387039363
XMax: 2854662.5384627134
YMax: 1027329.7824734747
Spatial Reference: 102719  (2264)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: PosXing
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: AT GRADE
  Label: At Grade
  Description: N/A
  Symbol:

• Value: RR OVER
  Label: Grade Separated
  Description: N/A
  Symbol:

• Value: RR UNDER
  Label: Grade Separated
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• CrossingId ( type: esriFieldTypeString, alias: CrossingID, length: 100 )
• Railroad ( type: esriFieldTypeString, alias: Railroad, length: 100 )
• PrfxMilePost ( type: esriFieldTypeString, alias: PrfxMilePost, length: 100 )
• MilePost ( type: esriFieldTypeDouble, alias: MilePost )
• SfxMilePost ( type: esriFieldTypeString, alias: SfxMilePost, length: 10 )
• XPurpose ( type: esriFieldTypeString, alias: XPurpose, length: 100 )
• PosXing ( type: esriFieldTypeString, alias: PosXing, length: 100 )
• Highway ( type: esriFieldTypeString, alias: Highway, length: 15 )
• Street ( type: esriFieldTypeString, alias: Street, length: 255 )
• Nearest ( type: esriFieldTypeString, alias: Nearest, length: 25 )
• CityCD ( type: esriFieldTypeString, alias: CityCD, length: 255 )
• CntyCD ( type: esriFieldTypeString, alias: CntyCD, length: 50 )
• PolCont ( type: esriFieldTypeString, alias: PolCont, length: 100 )
• Latitude ( type: esriFieldTypeDouble, alias: Latitude )
• Longitude ( type: esriFieldTypeDouble, alias: Longitude )
• Photo_N ( type: esriFieldTypeString, alias: Photo_N, length: 200 )
• Photo_S ( type: esriFieldTypeString, alias: Photo_S, length: 200 )
• Photo_E ( type: esriFieldTypeString, alias: Photo_E, length: 200 )
• Photo_W ( type: esriFieldTypeString, alias: Photo_W, length: 200 )
• DIVISION ( type: esriFieldTypeSmallInteger, alias: NCDOT Division )
• WARNING_TYPE ( type: esriFieldTypeString, alias: Warning Type, length: 50 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
